HQE10-PRO Technical Specifications

■ Superior Control & Maneuverability

• Hydraulic Pilot Joysticks: Move away from clunky mechanical levers. The HQE10-PRO offers smooth, fatigue-free operation, allowing for precise control in tight environments.

• Side-Swing Boom: Navigate obstacles with ease. The swing boom allows you to dig parallel to foundations and walls, reaching where others can't.

• Upgraded Lifting Boom: Optimized geometry for superior reach, featuring a Max. Digging Height of 2600mm and a Max. Digging Radius of 3100mm.

■ Professional Hydraulic System

• 3-Way Shut-off Valve (Optional): Designed for serious contractors. Switch between hydraulic attachments (like breakers and augers) quickly without oil loss or contamination.

• Standard Auxiliary Hydraulics: Ready-to-go dual-way piping for all your professional attachments.

■ Built for Compliance & Comfort

• EURO 5 Certified Engine: Equipped with the reliable KD192FC-1 (7kW) engine, meeting the latest emission standards for the EU and North American markets.

• 4-Post ROPS Canopy: Safety first. The heavy-duty 4-post structure provides full overhead protection without sacrificing 360-degree visibility.

• Premium Operator Station: Includes an ergonomic Headrest-equipped Seat to reduce operator fatigue during long shifts.

• Compact Footprint: With a 940mm width, it easily fits through standard garden gates and narrow job sites.
